Represents a rectangular region that can handle messages directed to that region. More...

#include <HandlerChain_MessageWindow_Class.h>

Inheritance diagram for MessageWindow:

Collaboration diagram for MessageWindow:

Public Types
using	shared_ptr_t = std::shared_ptr< MessageWindow >

Public Types inherited from IMessageHandler
using	shared_ptr_t = std::shared_ptr< IMessageHandler >
	Alias to make it easier when using a shared pointer.

Public Member Functions
bool	_PointInWindow (MessagePosition position)
	Determine if the specified point is in this MessageWindow's region.

bool	_PointInCloseBox (MessagePosition position)
	Determine if the specified point is in this MessageWindow's "close" region.

	MessageWindow (int windowId, std::string title, int x, int y, int width, int height, HandlerChain *handlerChain)
	Constructor.

int	ID ()
	Returns the ID of the message handler.

bool	ProcessMessage (Message *message)
	Processes a message.

std::string	ToString ()
	Convert this handler to a string.

Public Member Functions inherited from IMessageHandler
virtual	~IMessageHandler ()
	Virtual destructor (required for interfaces in C++)

virtual int	ID ()=0
	ID of the window. This is used to uniquely identify a window in the collection.

virtual bool	ProcessMessage (Message *message)=0
	Called with a message on each window.

virtual std::string	ToString ()=0
	Convert the handler to a string.

Static Public Member Functions
static MessageWindow::shared_ptr_t	CreateWindow (std::string title, int x, int y, int width, int height, HandlerChain *handlerChain)
	Creates an instance of the MessageWindow class with the specified attributes and adds the new instance to the given HandlerChain object.

static bool	_HandleButtonDownMessage (MessageWindow window, Message message)
	Helper method to handle the ButtonDown message.

static bool	_HandleButtonUpMessage (MessageWindow window, Message message)
	Helper method to handle the ButtonUp message.

static bool	_HandleCloseMessage (MessageWindow window, Message message)
	Helper method to handle the Close message.

Private Types
using	MessageHandler = bool()(MessageWindow window, Message *message)
	Alias for the function that handles the messages.

Private Attributes
const int	CLOSE_WIDTH = 2

const int	CLOSE_HEIGHT = 2

std::map< MessageType, MessageHandler >	_messageHandlers
	Maps a message type to a handler method of type MessageHandler.

int	_windowId
	Unique ID of this window.

std::string	_title
	Title/Name of this window.

WindowRectangle	_windowBox
	Position of this window in global coordinates.

WindowRectangle	_closeBox
	Position of the close window within the window box, although the coordinates are also global coordinates to eliminate the need to convert between window and global coordinates.

bool	_selected
	Whether this window has been selected (a button click occurred within the window).

HandlerChain *	_handlerChain
	The HandlerChain to which this window belongs (as an IMessageHandler object).

Static Private Attributes
static int	_nextWindowId = 1
	Used for assigning a unique ID to each created window.

Detailed Description

Represents a rectangular region that can handle messages directed to that region.

Note: The IMessageHandler interface is an example of a Facade design pattern, where the complexity of the MessageWindow is exposed only through a few methods to a system that only needs to deal with those few methods.

Definition at line 117 of file HandlerChain_MessageWindow_Class.h.

Member Typedef Documentation

◆ MessageHandler

using MessageHandler = bool (*)(MessageWindow* window, Message* message)

private

Alias for the function that handles the messages.

Definition at line 130 of file HandlerChain_MessageWindow_Class.h.

◆ shared_ptr_t

using shared_ptr_t = std::shared_ptr<MessageWindow>

Definition at line 120 of file HandlerChain_MessageWindow_Class.h.

Constructor & Destructor Documentation

◆ MessageWindow()

MessageWindow	(	int	windowId,
		std::string	title,
		int	x,
		int	y,
		int	width,
		int	height,
		HandlerChain *	handlerChain
	)

inline

Constructor.

Parameters

windowId	Unique ID of the window to use.
title	Title of the window.
x	Global x position of the upper left corner of the window's region.
y	Global y position of the upper left corner of the window's region.
width	Width of the window's region.
height	Height of the window's region.
handlerChain	A HandlerChain object that will be used for removal of this window when it is closed.

Definition at line 231 of file HandlerChain_MessageWindow_Class.h.

References MessageWindow::_HandleButtonDownMessage(), MessageWindow::_HandleButtonUpMessage(), MessageWindow::_HandleCloseMessage(), MessageWindow::_messageHandlers, DesignPatternExamples_cpp::ButtonDown, DesignPatternExamples_cpp::ButtonUp, and DesignPatternExamples_cpp::Close.

Member Function Documentation

◆ _HandleButtonDownMessage()

bool _HandleButtonDownMessage	(	MessageWindow *	window,
		Message *	message
	)

static

Helper method to handle the ButtonDown message.

Parameters

window	The window that is handling the message
message	A Message object describing the ButtonDown message.

Returns: Always returns false even if the message was handled (allows other windows to select/deselect themselves).

Definition at line 31 of file HandlerChain_MessageWindow_Class.cpp.

References MessageWindow::_PointInWindow(), MessageWindow::_selected, MessageWindow::_title, Helpers::formatstring(), and Message::Position.

Referenced by MessageWindow::MessageWindow().

◆ _HandleButtonUpMessage()

bool _HandleButtonUpMessage	(	MessageWindow *	window,
		Message *	message
	)

static

Helper method to handle the ButtonUp message.

Parameters

window	The window that is handling the message
message	A Message object describing the ButtonUp message.

Returns: Returns true if the message was handled; otherwise, returns false indicating the message was not handled.

Definition at line 62 of file HandlerChain_MessageWindow_Class.cpp.

References MessageWindow::_handlerChain, MessageWindow::_PointInCloseBox(), MessageWindow::_PointInWindow(), MessageWindow::_selected, MessageWindow::_title, DesignPatternExamples_cpp::Close, Helpers::formatstring(), Message::Position, and HandlerChain::SendMessage().

Referenced by MessageWindow::MessageWindow().

◆ _HandleCloseMessage()

bool _HandleCloseMessage	(	MessageWindow *	window,
		Message *	message
	)

static

Helper method to handle the Close message.

Parameters

window	The window that is handling the message
message	A Message object describing the Close message.

Returns: Returns true if the message was handled; otherwise, returns false indicating the message was not handled.

Definition at line 92 of file HandlerChain_MessageWindow_Class.cpp.

References MessageWindow::_handlerChain, MessageWindow::_selected, MessageWindow::_title, Helpers::formatstring(), and HandlerChain::RemoveHandler().

Referenced by MessageWindow::MessageWindow().

◆ _PointInCloseBox()

bool _PointInCloseBox ( MessagePosition position )

inline

Determine if the specified point is in this MessageWindow's "close" region.

Parameters

position The point to examine.

Returns: Returns true if the point is contained within the MessageWindow's "close" region.

Definition at line 213 of file HandlerChain_MessageWindow_Class.h.

References MessageWindow::_closeBox, and WindowRectangle::PointInside().

Referenced by MessageWindow::_HandleButtonUpMessage().

◆ _PointInWindow()

bool _PointInWindow ( MessagePosition position )

inline

Determine if the specified point is in this MessageWindow's region.

Parameters

position The global coordinate to examine.

Returns: Returns true if the point is contained within the MessageWindow's region.

Definition at line 200 of file HandlerChain_MessageWindow_Class.h.

References MessageWindow::_windowBox, and WindowRectangle::PointInside().

Referenced by MessageWindow::_HandleButtonDownMessage(), and MessageWindow::_HandleButtonUpMessage().

◆ CreateWindow()

MessageWindow::shared_ptr_t CreateWindow	(	std::string	title,
		int	x,
		int	y,
		int	width,
		int	height,
		HandlerChain *	handlerChain
	)

static

Creates an instance of the MessageWindow class with the specified attributes and adds the new instance to the given HandlerChain object.

Parameters

title	Title of the MessageWindow.
x	X position of the upper left corner of the window's region.
y	Y position of the upper left corner of hte window's region.
width	Width of the window's region.
height	Height of the window's region.
handlerChain	A HandlerChain object that will be given the window.

Returns: Returns the newly created MessageWindow.

Each MessageWindow instance is assigned a unique ID, which is required by the HandlerChain object.

Definition at line 15 of file HandlerChain_MessageWindow_Class.cpp.

References MessageWindow::_nextWindowId, and HandlerChain::AddHandler().

◆ ID()

int ID ( )

inlinevirtual

Returns the ID of the message handler.

Implements IMessageHandler.

Definition at line 292 of file HandlerChain_MessageWindow_Class.h.

References MessageWindow::_windowId.

Referenced by MessageWindow::ToString().

◆ ProcessMessage()

bool ProcessMessage ( Message * message )

inlinevirtual

Processes a message.

Parameters

message The Message object to process.

Returns: Returns true if the message was handled and no further windows should be notified; otherwise return false to allow the message to be passed to subsequent windows.

The message types are mapped to handlers in the MessageWindow constructor and stored in the _messageHandlers dictionary.

Implements IMessageHandler.

Definition at line 309 of file HandlerChain_MessageWindow_Class.h.

References MessageWindow::_messageHandlers, and Message::MessageType.

◆ ToString()

std::string ToString ( )

inlinevirtual

Convert this handler to a string.

Returns: Returns a string representation of the message handler.

Implements IMessageHandler.

Definition at line 329 of file HandlerChain_MessageWindow_Class.h.

References MessageWindow::_selected, MessageWindow::_title, MessageWindow::_windowBox, Helpers::formatstring(), MessageWindow::ID(), and WindowRectangle::ToString().

Member Data Documentation

◆ _closeBox

WindowRectangle _closeBox

private

Position of the close window within the window box, although the coordinates are also global coordinates to eliminate the need to convert between window and global coordinates.

Definition at line 157 of file HandlerChain_MessageWindow_Class.h.

Referenced by MessageWindow::_PointInCloseBox().
